Confirmed benchmark
22,000 L
Ground-truth volume supplied by Palatial. This benchmark is retained for independent validation only and is not passed into the automated calculation.
Palatial Pools · Evidence Report
Satellite volume takeoff
56 Studley Street, Abbotsford VIC 3067
Current automated status
Evidence-gated. No false takeoff issued.
Live visual analysis is currently unavailable. This pack therefore does not substitute an estimated automated volume or AI outline.
Supplied satellite evidence
Rear-yard pool target
Site observation: the pool lies behind and north-west of the street-front address marker. The measurement workflow therefore searches the full lot and ranks rear-yard candidates before final waterline review.
Calculation release criteria
What must happen before a volume is released
Correct pool outline
Final visual review must accept the rear-yard pool waterline and reject spas, water features and neighbour pools.
Evidence trace
Frame set, candidate ranking, scale control, DCT support, depth source and confidence tier must be stored with the result.
Benchmark comparison
The independent automatic estimate is compared against 22,000 L, then its error and pass or fail status are reported.
Workflow evidence ledger
Release-state trace
| Stage | Verified record | State |
|---|---|---|
| Property context | Supplied evidence locates the target in the rear north-west yard, not at the street-front pin. | Recorded |
| Frame strategy | Workflow specifies zoom 19, 20 and 21 satellite frames at scale two. | Configured |
| Image evidence | Controlled JPEG quality-62 recompression and 8×8 DCT block evidence are restored from the previous Palatial implementation. | Restored |
| Final waterline | Independent visual confirmation of the rear-yard pool waterline is required before an automatic release. | Pending live review |
| Volume validation | Independent result must be compared with the confirmed 22,000 L benchmark; the benchmark is not used as an algorithm input. | Pending calculation |
